GESCHAKELDE VOEDING SINGLE OUTPUT 450W 5.0V/90A

€ 119,00 € 98,35
Artikelnummer
RSP50005
  • ArtikelnummerRSP50005
  • MerkMEANWELL
  • Aantal 3+   € 113,05 € 93,43
Print deze pagina Print deze pagina

Features

• Enclosed case, built-in fan, screw terminals
• Universal input
• Overload protection, current limiting, auto recovery
• Protections: short circuit/over load/over voltage
• Built-in active PFC function
• Low profile
• Built-in remote On/Off control
• Built-in remote sense
Technical Specifications

Input Voltage: 85...264V AC (47...63Hz)
120...370V DC
Input Inrush Current, Max.: 40A
Leakage Current, Max.: 2mA
Output Voltage Adjustment: -5/+10%
Over Load Protection: 105...130%
Withstand Voltage
I/P-O/P: 3000V AC
I/P-FG: 2000V AC
O/P-FG: 500V AC
Operating Temperature: -30...+70°C
Weight: 1300g
I/P = Input, O/P = Output, FG = Frame Ground


Part Nr. UA IA PA DUA URN h
  [V] [A] [W] [%] [mVp-p] [%]
RSP-500-3.3 3,3 0...90 297 2 120 81
RSP-500-4 4 0...90 360 2 120 83
RSP-500-5 5 0...90 450 2 150 84
RSP-500-12 12 0...41,7 500,4 1 150 88
RSP-500-15 15 0...33,4 501 1 150 88
RSP-500-24 24 0...21 504 1 150 89
RSP-500-27 27 0...18,6 502,2 1 150 89,5
RSP-500-48 48 0...10,5 504 1 150 90,5
UA = Output Voltage, IA = Output Current Range, PA = Output Power, Uadj = Output Voltage Adjustment, DUA = Output Voltage Tolerance, URN = Ripple & Noise, h = Efficiency
