GESCHAKELDE VOEDING SINGLE OUTPUT 297W 4.0V/90A
€ 119,00
€ 98,35
Artikelnummer
RSP50004
- ArtikelnummerRSP50004
- MerkMEANWELL
- Aantal 3+ € 113,05 € 93,43
Features
| • Enclosed case, built-in fan, screw terminals • Universal input • Overload protection, current limiting, auto recovery • Protections: short circuit/over load/over voltage • Built-in active PFC function • Low profile • Built-in remote On/Off control • Built-in remote sense |
 |
| Technical Specifications |
|
|
| Input Voltage: | 85...264V AC (47...63Hz) |
| 120...370V DC | |
| Input Inrush Current, Max.: | 40A |
| Leakage Current, Max.: | 2mA |
| Output Voltage Adjustment: | -5/+10% |
| Over Load Protection: | 105...130% |
| Withstand Voltage | |
| I/P-O/P: | 3000V AC |
| I/P-FG: | 2000V AC |
| O/P-FG: | 500V AC |
| Operating Temperature: | -30...+70°C |
| Weight: | 1300g |
| I/P = Input, O/P = Output, FG = Frame Ground |
|
|
|
| Part Nr. | UA | IA | PA | DUA | URN | h |
| [V] | [A] | [W] | [%] | [mVp-p] | [%] | |
| RSP-500-3.3 | 3,3 | 0...90 | 297 | 2 | 120 | 81 |
| RSP-500-4 | 4 | 0...90 | 360 | 2 | 120 | 83 |
| RSP-500-5 | 5 | 0...90 | 450 | 2 | 150 | 84 |
| RSP-500-12 | 12 | 0...41,7 | 500,4 | 1 | 150 | 88 |
| RSP-500-15 | 15 | 0...33,4 | 501 | 1 | 150 | 88 |
| RSP-500-24 | 24 | 0...21 | 504 | 1 | 150 | 89 |
| RSP-500-27 | 27 | 0...18,6 | 502,2 | 1 | 150 | 89,5 |
| RSP-500-48 | 48 | 0...10,5 | 504 | 1 | 150 | 90,5 |
| UA = Output Voltage, IA = Output Current Range, PA = Output Power, Uadj = Output Voltage Adjustment, DUA = Output Voltage Tolerance, URN = Ripple & Noise, h = Efficiency | ||||||
