GESCHAKELDE VOEDING 48.0V 0.63A 30W KROONSTEEN AANSLUITING
€ 21,95
€ 18,14
Artikelnummer
IRM3048ST
- ArtikelnummerIRM3048ST
- MerkMEANWELL
- Aantal 3+ € 20,85 € 17,23
Features
| • Enclosed type • IRM-30-_: for PCB mounting • IRM-30-_ST: for screw terminal mounting • Universal input • Protections: short circuit/over load/over voltage • Cooling by free air convection • Low no load power consumption • Insulation class II |
 |
| Technical Specifications |
|
|
| Input Voltage: | 85...264V AC (47...440Hz) |
| Input Inrush Current, Max.: | 45A |
| No Load Power Consumption, Max.: | 0,1W |
| Withstand Voltage: | 3000V AC |
| Operating Temperature: | -30...+70°C |
| Weight | |
| IRM-30-_: | 109g |
| IRM-30-_ST: | 120g |
|
|
| Part Nr. | UA | IA | PA | DUA | URN | h |
| [V] | [A] | [W] | [%] | [mVp-p] | [%] | |
| IRM-30-5 | 5 | 0...6 | 30 | 2,5 | 120 | 83 |
| IRM-30-12 | 12 | 0...2,5 | 30 | 2,5 | 150 | 88 |
| IRM-30-15 | 15 | 0...2 | 30 | 2,5 | 200 | 88 |
| IRM-30-24 | 24 | 0...1,3 | 31,2 | 2,5 | 240 | 88,5 |
| IRM-30-48 | 48 | 0...0,63 | 30,2 | 2,5 | 300 | 90 |
| IRM-30-5ST | 5 | 0...6 | 30 | 2,5 | 120 | 83 |
| IRM-30-12ST | 12 | 0...2,5 | 30 | 2,5 | 150 | 88 |
| IRM-30-15ST | 15 | 0...2 | 30 | 2,5 | 200 | 88 |
| IRM-30-24ST | 24 | 0...1,3 | 31,2 | 2,5 | 240 | 88,5 |
| IRM-30-48ST | 48 | 0...0,63 | 30,2 | 2,5 | 300 | 90 |
| UA = Output Voltage, IA = Output Current Range, PA = Output Power, DUA = Output Voltage Tolerance, URN = Ripple & Noise, h = Efficiency | ||||||
|
||||||
| Norms |
| TÜV EN60950-1, UL60950-1 |
|
| Approvals |
    |
