GESCHAKELDE VOEDING 15.0V 3.00A 45W KROONSTEEN AANSLUITING
€ 24,95
€ 20,62
Artikelnummer
IRM4515ST
- ArtikelnummerIRM4515ST
- MerkMEANWELL
- Aantal 3+ € 23,69 € 19,58
Features
| • Enclosed type • IRM-45-_: for PCB mounting • IRM-45-_ST: for screw terminal mounting • Universal input • Protections: short circuit/over load/over voltage • Cooling by free air convection • Low no load power consumption • Insulation class II |
 |
| Technical Specifications |
|
|
| Input Voltage: | 85...264V AC (47...440Hz) |
| Input Inrush Current, Max.: | 60A |
| No Load Power Consumption, Max.: | 0,1W |
| Withstand Voltage: | 3000V AC |
| Operating Temperature: | -30...+70°C |
| Weight | |
| IRM-45-_: | 195g |
| IRM-45-_ST: | 228g |
|
|
| Part Nr. | UA | IA | PA | DUA | URN | h |
| [V] | [A] | [W] | [%] | [mVp-p] | [%] | |
| IRM-45-5 | 5 | 0...8 | 40 | 2,5 | 80 | 83,5 |
| IRM-45-12 | 12 | 0...3,8 | 45,6 | 2,5 | 150 | 87,5 |
| IRM-45-15 | 15 | 0...3 | 45 | 2,5 | 180 | 88,5 |
| IRM-45-24 | 24 | 0...1,9 | 45,6 | 2,5 | 200 | 89,5 |
| IRM-45-48 | 48 | 0...0,94 | 45,12 | 2,5 | 300 | 90,5 |
| IRM-45-5ST | 5 | 0...8 | 40 | 2,5 | 80 | 83,5 |
| IRM-45-12ST | 12 | 0...3,8 | 45,6 | 2,5 | 150 | 87,5 |
| IRM-45-15ST | 15 | 0...3 | 45 | 2,5 | 180 | 88,5 |
| IRM-45-24ST | 24 | 0...1,9 | 45,6 | 2,5 | 200 | 89,5 |
| IRM-45-48ST | 48 | 0...0,94 | 45,12 | 2,5 | 300 | 90,5 |
| UA = Output Voltage, IA = Output Current Range, PA = Output Power, DUA = Output Voltage Tolerance, URN = Ripple & Noise, h = Efficiency | ||||||
|
||||||
| Norms |
| TÜV EN60950-1, UL60950-1 |
|
| Approvals |
    |
