HEADER 20P FEMALE SINGLE IN LINE HOOG RASTER 2.54MM
€ 1,06
€ 0,88
Artikelnummer
FL120TG
- ArtikelnummerFL120TG
- MerkMPE GARRY
- Aantal 10+ € 0,90 € 0,74
Features
Tin-plated and gold-plated design
Suitable for square pins 0,64x0,64mm
Technical Specifications
Insulation Shell: Thermoplastic (UL94V-0)
Contact Material: Phosphor-Bronze
Contact Shell
BL1_Z: Tinned
BL1_TG: Gold-plated
Insulation Resistance: £40mW
Rated Current: 3A
Rated Voltage: 250VRMS/250V DC
Dielectric Strength (1Min.): 500V AC
Temperature Range: -40...+105°C
Short Term (Max. 10s): 260°C
Solderability: IEC 68-2-20 Tb
Tin-plated and gold-plated design
Suitable for square pins 0,64x0,64mm
Technical Specifications
Insulation Shell: Thermoplastic (UL94V-0)
Contact Material: Phosphor-Bronze
Contact Shell
BL1_Z: Tinned
BL1_TG: Gold-plated
Insulation Resistance: £40mW
Rated Current: 3A
Rated Voltage: 250VRMS/250V DC
Dielectric Strength (1Min.): 500V AC
Temperature Range: -40...+105°C
Short Term (Max. 10s): 260°C
Solderability: IEC 68-2-20 Tb
