EMI NETFILTER 1 FASE 1 TRAPS 250V 3A MET 6,3MM FASTON AANSLUITING
€ 24,50
€ 20,25
Artikelnummer
FN2020-3F
- ArtikelnummerFN2020-3F
- MerkSCHAFFNER
- Aantal 5+ € 22,05 € 18,22
Features
| • Single phase filters, one-stage, built in a metal housing • Compact design • Universal application • FN2020_-F: Faston plug terminal 6,3x0,8mm • FN2020_-M: Studs (M4 screws) |
 |
| Technical Specifications |
|
|
| Continuous Operating Voltage, Max.: | 250V AC, 50/60Hz; 250V DC |
| Dielectric Strength, 2s | |
| Line To Ground: | 2kV AC |
| Line To Ground B-Type: | 2,5kV AC |
| Line to Neutral (1A bis 20A Types) | 0,76kV AC |
| Line to Neutral (30A Types) | 1,1kV DC |
| Temperature Range: | -25...+100°C |
|
|
| Part Nr. | IR | L | CX | CY | IL |
| [A] | [mH] | [µF] | [nF] | [mA] | |
| FN2020-1F | 1 | 12 | 0,15 | 4,7 | 0,66 |
| FN2020-3F | 3 | 2,5 | 0,15 | 4,7 | 0,66 |
| FN2020-6F | 6 | 1 | 0,15 | 4,7 | 0,66 |
| FN2020-10F | 10 | 0,8 | 0,15 | 4,7 | 0,66 |
| FN2020-12F | 12 | 0,7 | 0,15 | 4,7 | 0,66 |
| FN2020-16F | 16 | 0,65 | 0,15 | 4,7 | 0,66 |
| FN2020-20F | 20 | 0,6 | 0,15 | 10 | 0,66 |
| FN2020-20M | 20 | 0,6 | 0,15 | 10 | 0,66 |
| FN2020-30M | 30 | 0,67 | 0,47 | - | 0,00 |
| IR = Rated Current, at 40°C, L = Inductance, IL = Leakage Current, Max. at 250V AC, 50Hz | |||||
|
|||||
| Approvals |
