ELCO BUS 4700UF 63V SOLDEERAANSLUITING EN SCHROEFBEVESTIGING
€ 13,50
€ 11,16
Artikelnummer
EBE47A
- ArtikelnummerEBE47A
- MerkF&T
- Aantal 5+ € 11,47 € 9,48
Capacitance CR 4700 µF
Capacitance tolerance ± 20%
Rated voltage 63V
Surge voltage US
UR ≤ 315 V: US = 1,15 UR
UR > 315 V: US = 1,10 UR
Max. reverse voltage 2 V
Category temperature range - 40°C ... + 105°C
Leakage current IL after 5 min @ UR ≤ 0,008 * CR [µF] * UR [V] + 6 µA [µA]
Voltage proof of the external insulation ³ 2500 V AC
Sectional specification IEC 60384-4
Capacitance tolerance ± 20%
Rated voltage 63V
Surge voltage US
UR ≤ 315 V: US = 1,15 UR
UR > 315 V: US = 1,10 UR
Max. reverse voltage 2 V
Category temperature range - 40°C ... + 105°C
Leakage current IL after 5 min @ UR ≤ 0,008 * CR [µF] * UR [V] + 6 µA [µA]
Voltage proof of the external insulation ³ 2500 V AC
Sectional specification IEC 60384-4
