DIN-RAIL 17.5MM VOEDING 15W 48V/0.32A

MEANWELL
Artikelnummer: HDR1548
Uw prijs:
€ 14,01 Excl. BTW:
€ 16,95 Incl. BTW:
- +

Extra informatie

print

Features

• Direct assembly on DIN Rail
• Enclosed case, Touch-guard screw terminals
• Universal input
• Overload protection, current limiting, auto recovery
• Protections: short circuit/over load/over voltage
• Low no load power consumption
• Power-on LED display
• Insulation Class II
Technical Specifications

Input Voltage: 85...264V AC (47...63Hz)
120...370V DC
Input Inrush Current, Max.: 45A
Over Load Protection: 110...145%
Withstand Voltage, I/P-O/P: 4000V AC
Operating Temperature: -30...+70°C
Weight: 78g
I/P = Input, O/P = Output


Part Nr. UA IA PA DUA URN h
  [V] [A] [W] [%] [mVp-p] [%]
HDR-15-5 5 0...2,4 12 2 80 80
HDR-15-12 12 0...1,25 15 1 120 85
HDR-15-15 15 0...1 15 1 120 85,5
HDR-15-24 24 0...0,63 15,2 1 150 86
HDR-15-48 48 0...0,32 15,4 1 240 87
UA = Output Voltage, IA = Output Current Range, PA = Output Power, DUA = Output Voltage Tolerance, URN = Ripple & Noise, h = Efficiency
