DIN-RAIL 17.5MM VOEDING 15W 24V/0.63A
€ 15,95
€ 13,18
Artikelnummer
HDR1524
- ArtikelnummerHDR1524
- MerkMEANWELL
- Aantal 3+ € 15,15 € 12,52
Features
| • Direct assembly on DIN Rail • Enclosed case, Touch-guard screw terminals • Universal input • Overload protection, current limiting, auto recovery • Protections: short circuit/over load/over voltage • Low no load power consumption • Power-on LED display • Insulation Class II |
 |
| Technical Specifications |
|
|
| Input Voltage: | 85...264V AC (47...63Hz) |
| 120...370V DC | |
| Input Inrush Current, Max.: | 45A |
| Over Load Protection: | 110...145% |
| Withstand Voltage, I/P-O/P: | 4000V AC |
| Operating Temperature: | -30...+70°C |
| Weight: | 78g |
| I/P = Input, O/P = Output |
|
|
|
| Part Nr. | UA | IA | PA | DUA | URN | h |
| [V] | [A] | [W] | [%] | [mVp-p] | [%] | |
| HDR-15-5 | 5 | 0...2,4 | 12 | 2 | 80 | 80 |
| HDR-15-12 | 12 | 0...1,25 | 15 | 1 | 120 | 85 |
| HDR-15-15 | 15 | 0...1 | 15 | 1 | 120 | 85,5 |
| HDR-15-24 | 24 | 0...0,63 | 15,2 | 1 | 150 | 86 |
| HDR-15-48 | 48 | 0...0,32 | 15,4 | 1 | 240 | 87 |
| UA = Output Voltage, IA = Output Current Range, PA = Output Power, DUA = Output Voltage Tolerance, URN = Ripple & Noise, h = Efficiency | ||||||
