DC/DC CONVERTER 36-72V -> +/-15V 80-400MA 12W

€ 29,95 € 24,75
Artikelnummer
DCW12C15
  • ArtikelnummerDCW12C15
  • MerkMEANWELL
  • Aantal 5+   € 26,95 € 22,27
Print deze pagina Print deze pagina
Features
• DIL24 housing
• For direct PCB mounting
• Wide input voltage range 2:1
• DC decoupling of input and output
• Built-in remote On/Off control
• Input/output insulation 1500V
• Regulated output voltage
• Short-circuit proof

Technical Specifications
Output Power: 12W
Over Load Protection: 110...180%
Withstand Voltage: 1500V DC
Operating Temperature: -25...+71°C
Weight: 18,5g


Input Voltage : 36...72Vdc
Output Voltage 1: +15V
Output Current Range 1: 80...400mA
Output Voltage 2: -15V
Output Current Range 2: 80...400mA
Ripple & Noise: 60mV
Efficiency: 83%
