DC/DC CONVERTER 36-72V -> +/-5V 240-1200MA 12W
€ 29,95
€ 24,75
Artikelnummer
DCW12C05
- ArtikelnummerDCW12C05
- MerkMEANWELL
- Aantal 5+ € 26,95 € 22,27
Features
DIL24 housing
For direct PCB mounting
Wide input voltage range 2:1
DC decoupling of input and output
Built-in remote On/Off control
Input/output insulation 1500V
Regulated output voltage
Short-circuit proof
Technical Specifications
Output Power: 12W
Over Load Protection: 110...180%
Withstand Voltage: 1500V DC
Operating Temperature: -25...+71°C
Weight: 18,5g
Input Voltage : 36....72Vdc
Output Voltage 1: +5V
Output Current Range 1:240...1200mA
Output Voltage 2: -5V
Output Current Range 2:240...1200mA
Ripple & Noise: 50mV
Efficiency: 81%
DIL24 housing
For direct PCB mounting
Wide input voltage range 2:1
DC decoupling of input and output
Built-in remote On/Off control
Input/output insulation 1500V
Regulated output voltage
Short-circuit proof
Technical Specifications
Output Power: 12W
Over Load Protection: 110...180%
Withstand Voltage: 1500V DC
Operating Temperature: -25...+71°C
Weight: 18,5g
Input Voltage : 36....72Vdc
Output Voltage 1: +5V
Output Current Range 1:240...1200mA
Output Voltage 2: -5V
Output Current Range 2:240...1200mA
Ripple & Noise: 50mV
Efficiency: 81%
