DC/DC CONVERTER 18-36V -> +/-15V 80-400MA 12W
€ 23,06
€ 19,06
Artikelnummer
DCW12B15
- ArtikelnummerDCW12B15
- MerkMEANWELL
- Aantal 5+ € 20,75 € 17,15
Features
DIL24 housing
For direct PCB mounting
Wide input voltage range 2:1
DC decoupling of input and output
Built-in remote On/Off control
Input/output insulation 1500V
Regulated output voltage
Short-circuit proof
Technical Specifications
Output Power: 12W
Over Load Protection: 110...180%
Withstand Voltage: 1500V DC
Operating Temperature: -25...+71°C
Weight: 18,5g
Input Voltage : 18....36Vdc
Output Voltage 1: +15V
Output Current Range 1: 80...400mA
Output Voltage 2: -15V
Output Current Range 2: 80...400mA
Ripple & Noise: 60mV
Efficiency: 84%
