DC/DC CONVERTER 18-36V -> +/-12V 100-500MA 12W

Features
• DIL24 housing
• For direct PCB mounting
• Wide input voltage range 2:1
• DC decoupling of input and output
• Built-in remote On/Off control
• Input/output insulation 1500V
• Regulated output voltage
• Short-circuit proof

Technical Specifications
Output Power: 12W
Over Load Protection: 110...180%
Withstand Voltage: 1500V DC
Operating Temperature: -25...+71°C
Weight: 18,5g


Input Voltage : 18...36Vdc
Output Voltage 1: +12V
Output Current Range 1: 100...500mA
Output Voltage 2: -12V
Output Current Range 2: 100...500mA
Ripple & Noise: 60mV
Efficiency: 84%
