MICROSWITCH 1XOM 3A/125VAC MET HENDEL
€ 1,82
€ 1,50
Artikelnummer
D2F223
- ArtikelnummerD2F223
- MerkOMRON
- Aantal 10+ € 1,63 € 1,35
Features
Extremely small housing: only 12,8x6x5,8mm
Two different actuators
Housing protected against solder and flux penetration (IP40)
Long operating life due to an incorporated snapping mechanism made with two highly precise split springs
Technical Specifications
Operating Force: 1,47N
Nr. of Contacts: 1 SPD
Switching Capacity, Max.: 3A, 125V AC 2A, 30V DC
Switching Frequency: 30 Switches/Min. 1...500mm/s
Test Voltage Contacts/Ground: 1500V AC, 1min.
Electrical Operating Life: 30,000 Switches
Mechanical Operating Life: 1,000,000 Switches
Ambient Temperature: -25...85°C
Extremely small housing: only 12,8x6x5,8mm
Two different actuators
Housing protected against solder and flux penetration (IP40)
Long operating life due to an incorporated snapping mechanism made with two highly precise split springs
Technical Specifications
Operating Force: 1,47N
Nr. of Contacts: 1 SPD
Switching Capacity, Max.: 3A, 125V AC 2A, 30V DC
Switching Frequency: 30 Switches/Min. 1...500mm/s
Test Voltage Contacts/Ground: 1500V AC, 1min.
Electrical Operating Life: 30,000 Switches
Mechanical Operating Life: 1,000,000 Switches
Ambient Temperature: -25...85°C
