HEADER 20P FEMALE SINGLE IN LINE RASTER 2.54MM
€ 2,95
€ 2,44
Artikelnummer
BL1X20PF
- ArtikelnummerBL1X20PF
- MerkMPE GARRY
- Aantal 10+ € 2,50 € 2,07
Precision Female Headers
Series: BL10, BL20S Single and Double Row, Straight Height: 7,0mm Pitch:2,54mm
Features
Selective gold-plated design
With 6 beryllium copper fingerclips
Suitable for square pins 0,64x0,64mm or round pins with Ø 0,7...0,8mm
BL20S_: Star-shaped opening between the contacts for easy cutting
Technical Specifications
Insulation Shell: High Temp. Thermoplast (UL94V-0), Black
Contact Material
Solder Pin: Cu-alloy
Clip: BeCu
Contact Surface: Au (Selective Gold-plated.)
Rated Current: 3A
Rated Voltage: 250VRMS/250V DC
Breakdown Voltage, Min.: 1000VRMS
Temperature Range: -55...+125°C
Solderability, Max.: 260°C, 10s
Series: BL10, BL20S Single and Double Row, Straight Height: 7,0mm Pitch:2,54mm
Features
Selective gold-plated design
With 6 beryllium copper fingerclips
Suitable for square pins 0,64x0,64mm or round pins with Ø 0,7...0,8mm
BL20S_: Star-shaped opening between the contacts for easy cutting
Technical Specifications
Insulation Shell: High Temp. Thermoplast (UL94V-0), Black
Contact Material
Solder Pin: Cu-alloy
Clip: BeCu
Contact Surface: Au (Selective Gold-plated.)
Rated Current: 3A
Rated Voltage: 250VRMS/250V DC
Breakdown Voltage, Min.: 1000VRMS
Temperature Range: -55...+125°C
Solderability, Max.: 260°C, 10s
