ADAPTER 24V 1500MA GESCHAKELD
€ 24,50
€ 20,25
Artikelnummer
PSS2415
- ArtikelnummerPSS2415
- MerkMEANWELL
- Aantal 3+ € 22,05 € 18,22
| Features |
| • Plug-in switching power supply with europlug • Universal input • Overload protection, pulsing hiccup shutdown, auto recovery • Protections: short circuit/over load/over voltage • Insulation Class II • Low no load power consumption |
 |
| Technical Specifications |
|
|
| Input Voltage: | 90...264V AC (47...63Hz) |
| 135...370V DC | |
| Input Inrush Current, Max.: | 60A |
| No Load Power Consumption, Max.: | 0,3W |
| Operating Temperature: | -20...+50°C |
| Cable Length: | 1m |
| Input Plug: | Euro |
| Output Plug, Coax: | 2,1x5,5mm |
| Weight: | 226g |
|
|
1" align="center" valign="top">84,5
| Part Nr. | UA |
IA |
PA |
DUA |
URN |
h |
| [V] | [A] | [W] | [%] | [mVp-p] | [%] | |
| GS36E24-P1J | 24 | 0...1,5 | 36 | 2 | 180 | 85,5 |
| UA = Output Voltage, IA = Output Current Range, PA = Output Power, DUA = Output Voltage Tolerance, URN = Ripple & Noise, h = Efficiency | ||||||
