TRANSFORMATOR 3.0VA 2X9V 2X167MA
€ 4,50
€ 3,72
Artikelnummer
2090030M
- Artikelnummer2090030M
- MerkHAHN
- Aantal 5+ € 4,04 € 3,34
Transformer 3VA 230V 2x6V 2x167mA
Features
Winding of double coated copper wire for better insulation, vacuum casted, two chambers
Connections for PCB use
Technical Specifications
Temperature Resistance Class1): Ta 40/F
End Temperatur in Case of Short-Circuit, Max.2): 190°C
End Temperature in Standard Use: 140°C
Permissible Overtemperature3): 100K
Primary Voltage (50/60Hz): 230V AC
Power, Max. (Ta 40/F)2): 3VA
Test Voltage: 4kV/50Hz
No-Load Voltage (According to VDE 0570): <2 x UN sec.
Features
Winding of double coated copper wire for better insulation, vacuum casted, two chambers
Connections for PCB use
Technical Specifications
Temperature Resistance Class1): Ta 40/F
End Temperatur in Case of Short-Circuit, Max.2): 190°C
End Temperature in Standard Use: 140°C
Permissible Overtemperature3): 100K
Primary Voltage (50/60Hz): 230V AC
Power, Max. (Ta 40/F)2): 3VA
Test Voltage: 4kV/50Hz
No-Load Voltage (According to VDE 0570): <2 x UN sec.
