Design
 |
|
| Motor: | Patented One-phase Single Coil |
| DC Brushless Motor Design | |
| Frame: | Thermoplastic PBT (UL94V-0) |
| Impeller: | Thermoplastic PBT (UL94V-0) |
| Bearing System: | Ball |
| IP Protection Class | |
| CF4113_AA9: | IP21 |
| CF4113_AB9: | IP55 |
| CF4113_AE9: | IP68 |
| CF4113_ABD: | IP55 Atex Certification |
| Lead Wire: | UL 3266, 24AWG |
|
|
| Technical Specifications |
|
|
| Rated Voltage: | 110/230V AC |
| CF4113_ABD: | 100/240V AC |
| Operating Voltage: | 90...265V AC |
| Dielectric Strength at 65% r. F.: | 1800V AC for 1s |
| Insulation Resistance at 500V DC: | >10MOhm |
| Storage Temperature: | -40...+80°C |
| Operating Temperature: | -25...+70°C |
|
|
| Part Nr. | Speed | PAirflow | Noise | I | Pel |
| [RPM] | [m3/h] | [dBA] | [A] | [W] | |
| F2312038BG | 185,14 | 44,9 | 0,081 | 5,1 | 3500 |
| F2312038BH | 185,14 | 44,9 | 0,081 | 5,1 | 3500 |
| F2312038BI | 185,14 | 44,9 | 0,081 | 5,1 | 3500 |
| F2312038BJ | 153,04 | 40,2 | 0,061 | 3,4 | 3000 |
| F2312038BK | 153,04 | 40,2 | 0,061 | 3,4 | 3000 |
| F2312038BL | 153,04 | 40,2 | 0,061 | 3,4 | 3000 |
| F2312038BM | 109,22 | 31,4 | 0,037 | 1,8 | 2000 |
| F2312038BN | 109,22 | 31,4 | 0,037 | 1,8 | 2000 |
| F2312038BP | 109,22 | 31,4 | 0,037 | 1,8 | 2000 |
